BOSCH REXROTH
R901518900
$6,415.92 USD
- BOSCH REXROTH
- Material:R901518900
- Model:H-4WEH32J6X/6EG24N9ES2K4/10B10D3
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth H-4WEH32J6X/6EG24N9ES2K4/10B10D3 (R901518900) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction in accordance with its hydraulic symbol J. This solenoid-actuated spool valve is pilot-operated, featuring an internal pilot oil supply and external pilot oil return, ensuring efficient control of the hydraulic system. The valve's max pressure capability ensures it can handle demanding applications, while the electrical connection is facilitated via a connector pole PE conforming to EN standards. The product has a size designation that aligns with industry standards, and its type of actuation is achieved through solenoid actuation. It offers a maximum flow rate suitable for various hydraulic requirements and supports subplate mounting for secure installation. The connection diagrams are in compliance with NFPA T.. R D SizeCETOP and ISO standards, ensuring compatibility with a wide range of systems. This Bosch Rexroth valve operates at a supply voltage of 24 VDC and features multiple switching positions to accommodate different operational needs. Weighing in at . kg, it is robust yet manageable for installation. It comes equipped with NBR seals and can work with various types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. This combination of features makes the H-4WEH32J6X/6EG24N9ES2K4/10B10D3 (R901518900) an optimal choice for those seeking a reliable solution to manage their hydraulic systems effectively.
The Bosch Rexroth H-4WEH32J6X/6EG24N9ES2K4/10B10D3 (R901518900) is a high-performance industrial hydraulic valve designed for reliable switching of oil flow direction in accordance with its hydraulic symbol J. This solenoid-actuated spool valve is pilot-operated, featuring an internal pilot oil supply and external pilot oil return, ensuring efficient control of the hydraulic system. The valve's max pressure capability ensures it can handle demanding applications, while the electrical connection is facilitated via a connector pole PE conforming to EN standards. The product has a size designation that aligns with industry standards, and its type of actuation is achieved through solenoid actuation. It offers a maximum flow rate suitable for various hydraulic requirements and supports subplate mounting for secure installation. The connection diagrams are in compliance with NFPA T.. R D SizeCETOP and ISO standards, ensuring compatibility with a wide range of systems. This Bosch Rexroth valve operates at a supply voltage of 24 VDC and features multiple switching positions to accommodate different operational needs. Weighing in at . kg, it is robust yet manageable for installation. It comes equipped with NBR seals and can work with various types of hydraulic fluids including HL, HLP, HLPD, HVLP, HVLPD, and HFC. This combination of features makes the H-4WEH32J6X/6EG24N9ES2K4/10B10D3 (R901518900) an optimal choice for those seeking a reliable solution to manage their hydraulic systems effectively.
Size 32, symbol J, electrical with solenoid, 24 V DC
Industrial hydraulic valve in a high performance range. Reliable switching of the oil flow direction according to hydraulic symbol.
Unpacked Weight: 38.216 kg
Internal pilot oil supply, external pilot oil return |
Spool valve |
Pilot-operated |
Size 10 … 32 |
Maximum operating pressure 350 bar |
Maximum flow 1100 l/min |
Component series 4X, 7X, 6X |
Data Sheet | Download Data Sheet |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Manual | Download Manual |
Spool symbol | Symbol J |
Max. pressure | 350 |
Electrical connection description | Connector 3-pole (2 + PE) according to EN 175301-803 |
Productgroup ID | 9,10,11,12,13,14 |
Number of ports | 4 |
Type of actuation | with solenoid actuation |
Size | 32 |
Electrical connector | Connector 3-pole (2 + PE) |
Max. flow | 1100 |
Type of connection | Subplate mounting |
Connection diagram NFPA | NFPA T3.5.1 R2-2002 D10 |
Size_CETOP | 0 |
Connection diagram | ISO 4401-10-09-0-05 |
Supply voltage | 24 VDC |
Number of switching positions | 3 |
Weight | 38.216 |
Seals | NBR |
Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
Hydraulic fluid | HL,HLP,HLPD,HVLP,HVLPD,HFC |
