BOSCH REXROTH
R109922087

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSADR1T-20-WV-1200 (R109922087) is a high-quality linear motion set designed for precision applications requiring robustness and resistance to torque loads. This linear set includes a lightweight precision tandem housing made of aluminum, which houses two torque-resistant linear bushings. These bushings are paired with a precision steel shaft featuring one ball guide groove, ensuring smooth and accurate linear motion. The shaft diameter 'd' and the standard length conform to the specifications in the provided table, while the absence of an external seal contributes to the product's streamlined design. The bearing plates are hardened steel, set to zero clearance ex-factory, which allows for precise movements without play. This configuration provides stability against cocking loads and is capable of transmitting torque effectively. Furthermore, this linear set is relubricatable, extending its service life by allowing for maintenance and lubrication as needed. The dynamic load capacity 'C' indicates that it can handle significant loads when both bushings are under equal load, although these values are minimal since the direction of loading may vary. Designed for applications with specific environmental conditions, this product can operate within a permissible ambient temperature range from 'min temperature' to 'max temperature'. Its outer diameter 'D', maximum permissible linear speed 'vmax', and mass 'm kg/m' have been meticulously calculated to ensure optimal performance within its intended operational parameters. In summary, the Bosch Rexroth LINEAR-SET LSADR1T-20-WV-1200 is tailored for applications that demand high precision and resistance to torsional forces. Its construction quality and design features make it suitable for various uses where reliability and accuracy are paramount.
