BOSCH REXROTH
R109721685

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSSDR1T-16-WV-900 (R109721685) is a high-precision linear motion set designed to provide reliable and smooth linear movement in various applications. This robust assembly features a precision steel shaft with a diameter of 16mm, which comes standard in length as per the provided table, ensuring compatibility with a wide range of installations. The shaft includes one ball guide groove and is accompanied by two torque-resistant linear bushings that are pre-set to zero clearance ex works for optimal performance. The LINEAR-SET LSSDR1T-16-WV-900 is constructed from standard steel, which contributes to its stability against cocking loads, making it suitable for applications where high torsional rigidity is required. It does not include external seals, which allows for easy maintenance and inspection. The tandem ball guide grooves enhance the system's load-carrying capacity and ensure that both linear bushings are under equal load during operation. This set's dynamic load capacity C and static load rating C0 reflect minimal values due to the variable nature of loading directions in different applications. The product also boasts an impressive dynamic torsional moment load capacity (Mt), further demonstrating its ability to withstand demanding operational conditions. With a permissible ambient temperature range from -20°C to +80°C, the LINEAR-SET LSSDR1T-16-WV-900 can operate effectively in various environmental conditions without compromising its performance. Its maximum permissible linear speed (vmax) and acceleration (amax) specifications ensure swift and efficient motion control. The unit's mass is indicated in kg/m, providing users with critical information for calculating the overall weight of their assembly. As part of Bosch Rexroth's product group ID, this linear set adheres to stringent quality standards, ensuring reliability and longevity in its service life. Overall, the LINEAR-SET LSSDR1T-16-WV-900 offers an exceptional solution for those requiring precise linear guidance with high torsional resistance capabilities.
