BOSCH REXROTH
R106828000

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth LINEAR-SET LSGOE-M-80-DD (R106828000) is a comprehensive linear motion set designed for precision applications. This set includes a standard linear bushing with integrated wiper seals to ensure the protection of internal mechanisms from contaminants while maintaining smooth motion. The bushing is secured with a locating screw, enhancing stability and accuracy. With an open and adjustable design, this linear set allows for zero-clearance or preloaded guides, catering to the specific requirements of various applications. The shaft diameter 'd' facilitates compatibility with corresponding components, while the two seals offer additional protection and longevity to the system. The precision housing is crafted from lamellar graphite cast iron steel, ensuring durability and consistent performance. The product features a standard metal size V in the series, with size B for the linear bushing and size E noted in specifications related to dynamic load capacity. The LINEAR-SET LSGOE-M-80-DD boasts an impressive dynamic load capacity 'C', which applies to the main direction of loading. It also has a specified maximum acceleration 'amax' and can operate within a permissible ambient temperature range, making it versatile for different working environments. Additionally, this linear set offers low frictional drags generated by its bushings when not under radial load, which depends on speed and lubrication conditions. Its outer diameter 'D', breakaway force, maximum permissible linear speed 'vmax', static load rating 'C', friction force, and radial clearance are all engineered for optimal performance in demanding applications. The product comes clamped to an h shaft lower limit and is set to zero-clearance as part of its precise manufacturing process. The weight specification ensures that it can be integrated into systems without significantly affecting overall mass. Overall, the LINEAR-SET LSGOE-M-80-DD is designed to provide reliable linear motion solutions for OEMs across various sectors requiring high precision guidance systems.
