BOSCH REXROTH
R911171737
$8,132.41 USD
- BOSCH REXROTH
- Material:R911171737
- Model:VDP60.3FEN-D1-NN-NN
Quantity in stock: 0
xxx
Unpacked Weight: 8.26 kg
| 3D CAD | Download 3D CAD |
| Productgroup ID | 4,6 |
| International protection code | Front IP65 |
| Operation | Touch screen with front USB |
| Screen type | TFT |
| Display resolution | 1280 x 1024 Pixel |
| Screen size | 19" Display / 16:9 |
| Weight | 8.26 |
General data
|
Type |
VDP60.3FE | |
|
Color |
RAL 7035 light gray | |
|
Weight |
kg |
7.3 |
|
Ambient temperature (operation) |
+5 °C ... +45 °C | |
|
Permissible relative humidity (operation) |
5 % ... 85 %, EN 61131-2 | |
|
Protection type front |
IP65 | |
Display
|
Type |
VDP60.3FE | |
|
Type |
TFT - - |
|
|
Size |
48.3 cm/19 in | |
|
Colors/grayscales |
16 mill. colors | |
|
Resolution |
1280 x 1024 | |
Operation
|
Type |
VDP60.3FE | |
|
Type |
Touch operation - - |
|
|
Status LED |
Voltage Hard disk Temperature UPS |
|
Interfaces
|
Type |
VDP60.3FE | |
|
Type |
1 x USB Front 4 x USB 1 x CDI interface – connection of industrial PC to display/terminal - |
|
Electrical data
|
Type |
VDP60.3FE | |
|
Supply voltage U |
V DC |
24 |
|
Umin ... Umax |
19 V DC ... 30 V DC | |
|
Power consumption |
W |
40 |
Mechanical tests
|
Type |
VDP60.3FE | |
|
Vibration resistance |
g |
1 |
|
Shock resistance |
g |
15 |
Slide-out keyboards
VAK40
Slide-out keyboards
VAK40
Slide-out keyboard with integrated mouse Overall width 407 mm, suitable for 15” devices Suitable for devices in the VDP40, VPP40 and VEP50 series Protection type IP65Project planning guide
CAD Download
Foil keyboards
VAK11/41
Foil keyboards
VAK11/41
Foil keyboard with separate numeric block Overall width 350 mm or 407 mm, suitable for 12” and 15” devices Suitable for devices in the VDP16/40, VPP16/40 and VEP40/50 series Protection type IP65Project planning guide
CAD Download
Box PC
VPB40.3
Box PC
VPB40.3
Industrial PCs for control cabinet installation High-performance automation platform 1-, 2-, 4-slot variant available Designed for tough industrial applicationsProject planning instructions
Operating instructions
CAD Download
Box PC
VPB40.4
Box PC
VPB40.4
Industrial PCs for control cabinet installation High-performance automation platform 2-, 4-slot variant available Designed for tough industrial applicationsOperating instructions
CAD Download
Dimensions
|
Type |
VDP60.3FE | |
|
A |
mm |
483 |
|
B |
mm |
400 |
|
C1 |
mm |
23.5 |
|
C2 |
mm |
54 |
|
X |
cm |
48.3 |
|
in |
19 | |
External 24 V power supply unit
VAP01
External 24 V power supply unit
VAP01
External 24 V power supply unit for VEP, VPP, VPB and VDP devices Input voltage 100-120 or 200-240 V AC Output voltage 24 V DC Output power up to 288 W Output current up to 12 AApplication description
Y-repeater
VAC01
Y-repeater
VAC01
Increases the maximum distance between the industrial PC and display/terminal to 100 m Connection of two displays/terminals to one industrial PC possible (with cascading design up to four displays/terminals per industrial PC) Assignment of operating rights via the 24 V input on the Y-repeater Same display on all displays/terminalsApplication description
Norms and Standards
|
Type |
VDP60.3FE | |
|
Certification |
CE UL CSA - - - - |
|
