BOSCH REXROTH
3842558795

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth STOP GATE VE 2/D-175 (3842558795) is a pneumatic stop gate designed for robust and efficient operation within automated material handling systems. This all-metal stop gate features a double piston damper that allows for infinitely adjustable damping, ensuring smooth and controlled stopping of workpiece pallets. With its short damping path of 10 mm and rapid damping time, the STOP GATE VE 2/D-175 provides precise stopping capabilities while maintaining a short installation dimension, making it ideal for integration into existing conveyor sections. The stop gate's sturdy construction is suitable for use in an Electrostatic Protected Area (EPA), with the ability to handle a minimum workpiece pallet weight as specified by the product group ID. The total weight capacity of the workpiece pallets that can be managed by this system is also defined by multiple product group IDs. Notably, the VE 2/D-175 is ESD compliant, ensuring it can safely operate in environments where electrostatic discharge could pose a risk to sensitive components. Operating at temperatures up to a specified maximum, the STOP GATE VE 2/D-175 requires a pneumatic straight connection with a maximum and minimum required compressed air connection pressure. The unit weighs in at an efficient mass and offers high temperature resistance upon special request. Its nominal speed range is detailed across various specifications. Included with the delivery are all necessary fastening materials for mounting on ST... conveyor sections. For optimal performance, the recommended accessory is the VE RS Return Stop. The material composition includes an aluminum housing that is hard-anodized for durability and a steel stop cam that has been hardened to withstand repetitive use. In operation, this dampened stop gate halts accumulating workpiece pallets at a defined surface while allowing subsequent pallets to accumulate behind. Once pressure is released, its spring mechanism closes the gate to halt further movement of the workpiece pallets. This functionality makes it highly suitable for applications where sequential processing or controlled flow of materials is essential.
