BOSCH REXROTH
3842557946

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth FRAME PROFILE 225X30 (3842557946) is a versatile and robust component designed for constructing trays and material shelves. This frame profile is specifically engineered to ensure a rattle-free installation of surface elements by mounting them under tension. It includes a corner piece that facilitates the right-angled connection of two frame profiles, streamlining the assembly process without the need for additional finishing. The product boasts an impressive moment of resistance in the y-direction (Wy), as well as a significant area moment of inertia in the y-direction (ly), which contributes to its stability and strength. In the x-direction, it also provides an adequate moment of resistance (Wx) along with an area moment of inertia (lx), ensuring that it can withstand various forces and stresses during use. Constructed from high-quality aluminum with an anodized finish, this frame profile is not only durable but also has aesthetic appeal. The aluminum material contributes to its lightweight nature, making it easier to handle and install while maintaining structural integrity. This product comes in standard lengths as part of its delivery unit and has a specified mass (m) that correlates with its size and material properties. Its length (L) is tailored to meet common application requirements, allowing for seamless integration into various designs. For added convenience, Bosch Rexroth recommends accessories such as the Bracket set M, Swivel fastening, Lettering clip for mm slot, Plate, Cover cap .x in black ESD, and Cover cap .x in signal gray. These accessories enhance the functionality and appearance of the frame profile while ensuring compatibility with various applications. Overall, the FRAME PROFILE 225X30 by Bosch Rexroth is designed to be a reliable solution for constructing frameworks that require precision, ease of assembly, and long-lasting performance.
