BOSCH REXROTH
3842546116
$833.65 USD
- BOSCH REXROTH
- Material:3842546116
- Model:SLIDING RAIL VFPLUS PREMIUM L30M
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth SLIDING RAIL (3842546116) is a high-quality conveyor component designed to facilitate the smooth and efficient movement of materials along a conveyor system. This VFplus Premium model is engineered for ease of assembly, simply clipping onto the section profile without the need for additional machining of the gliding surface. Thanks to its design, it is secured against axial shifting through lateral bolting, ensuring stability and reliability in operation. The slide rail's construction material meets FDA CFR standards for Premium and Advanced slide rails, making it suitable for applications that require adherence to strict hygiene regulations. It also satisfies EU standards for Basic slide rails. With its compatibility with all AL and STS section profiles, this product offers versatility across various conveyor setups. This particular model comes as a single rod with a standard length of 30 meters (L30M) and is part of product group ID. It is made from PE-UHMW material, which provides low friction and excellent wear resistance. The weight specifications and required accessories for installation include a slide rail assembly tool and sheet metal screws (size 5.5x13 according to DIN EN ISO). Designed to minimize abrasion and noise levels, the Bosch Rexroth SLIDING RAIL VFplus Premium L30M is ideal for sections with sliding curves, capable of handling speeds up to vmax = m/min in cleanroom environments. For optimal performance, extending the slide rail over component interfaces is recommended to ensure minimal wear and reduced noise emissions. If there's a need for an interruption after every m, lateral attachment with sheet metal screw A is necessary to maintain integrity. In summary, this sliding rail offers an efficient solution for enhancing conveyor system functionality while meeting stringent health and safety standards.
The Bosch Rexroth SLIDING RAIL (3842546116) is a high-quality conveyor component designed to facilitate the smooth and efficient movement of materials along a conveyor system. This VFplus Premium model is engineered for ease of assembly, simply clipping onto the section profile without the need for additional machining of the gliding surface. Thanks to its design, it is secured against axial shifting through lateral bolting, ensuring stability and reliability in operation. The slide rail's construction material meets FDA CFR standards for Premium and Advanced slide rails, making it suitable for applications that require adherence to strict hygiene regulations. It also satisfies EU standards for Basic slide rails. With its compatibility with all AL and STS section profiles, this product offers versatility across various conveyor setups. This particular model comes as a single rod with a standard length of 30 meters (L30M) and is part of product group ID. It is made from PE-UHMW material, which provides low friction and excellent wear resistance. The weight specifications and required accessories for installation include a slide rail assembly tool and sheet metal screws (size 5.5x13 according to DIN EN ISO). Designed to minimize abrasion and noise levels, the Bosch Rexroth SLIDING RAIL VFplus Premium L30M is ideal for sections with sliding curves, capable of handling speeds up to vmax = m/min in cleanroom environments. For optimal performance, extending the slide rail over component interfaces is recommended to ensure minimal wear and reduced noise emissions. If there's a need for an interruption after every m, lateral attachment with sheet metal screw A is necessary to maintain integrity. In summary, this sliding rail offers an efficient solution for enhancing conveyor system functionality while meeting stringent health and safety standards.
Slide rail VFplus Premium
Unpacked Weight: 2.2 kg
The slide rail is clipped into the section profile and guides the conveyor chain.
Lateral securing means the sliding surface does not need to be machined. Abrasion and noise levels are thus reduced to a minimum.
Three slide rails with different main areas of application are available:
Basic: straight sections and curve wheels, vmax 60 m/min Advanced: sections with sliding curves, vmax 60 m/min, clean room Premium: sections with sliding curves, vmax 100 m/min, clean room
Extend the slide rail over the component interfaces to ensure minimum wear and noise emissions. Interruptions to the profile or component connection must be avoided. If an interruption is necessary after 10 m, the slide rail must be attached laterally with a sheet metal screw (A).
| Easy assembly - simply clip onto the section profile |
| Secured against axial shifting due to lateral bolting |
| Gliding surface machining: not required |
| Material – for Premium, Advanced slide rails: FDA CFR 21 – for Basic slide rails: EU 10/2011, FDA CFR 21: Material – for Premium, Advanced slide rails: FDA CFR 21 – for Basic slide rails: EU 10/2011, FDA CFR 21 |
| One cross-section for all AL and STS section profiles |
| Data Sheet | Download Data Sheet |
| 3D CAD | Download 3D CAD |
| Condition on delivery | Single rod in standard length |
| Productgroup ID | 2 |
| Packaging unit | 1 |
| Length [L] | 30000 |
| Material | PE-UHMW |
| Weight | 2.2 |
| Required accessories | Slide rail assembly tool,Sheet metal screw 2.9x9.5 DIN 7982; DIN EN ISO 7050 1 screw per slide rail section |
| Size [b] | 65,90,120,160,240,320 |
|
Material |
|
| Slide rail VFplus Premium | PE-UHMW |
| Slide rail VFplus Advanced | |
| Slide rail VFplus Basic | |
| Sheet metal screw |
Note: After the sliding curves, an interruption is provided as an expansion joint in the inner curve area.
Slide rail assembly tool
