BOSCH REXROTH
JOINT 30X30
3842502683

***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Bosch Rexroth directly.***
The Bosch Rexroth JOINT 30X30 (3842502683) is a versatile and robust component designed for modular structural assembly. This standard joint, part of Bosch's line of connection solutions, is engineered to facilitate both movable and rigid profile connections at any angle, offering a swivel range of up to 182 degrees. Its utility is further enhanced by the presence of markings in 15-degree increments, which aid in precise alignment during assembly. The JOINT 30X30 is equipped with a through-hole D11 for end face profile connections, allowing for straightforward integration with compatible profiles. Locking the joint into place can be done by clamping, which requires a torque of 5 Nm, or by fixing with pins for a stronger hold at 15 Nm. This flexibility ensures that the joint can be tailored to meet the stability requirements of various applications. Moreover, this model sports the designLINE version's special silver paint finish in RAL 9006 color, lending an aesthetically pleasing and high-quality design aspect to the final construction. The paint not only enhances the visual appeal but also provides an additional layer of protection against environmental factors. The Bosch Rexroth JOINT 30X30 is suitable for creating custom structures where precision and variability in connection angles are necessary. It exemplifies Bosch's commitment to providing high-quality components that combine functionality with design excellence. Whether used in constructing frameworks for machinery, workstations, or other modular systems, this joint offers reliability and style.
