HENGST
1010814B
$3,864.93 USD
Tags:
- HENGST
- Material:1010814B
- Model:R928043913
- Summary:Hydraulic-Inline Filter
Quantity in stock: 0
***Disclaimer: The following summary contains information gathered from various sources such as product descriptions, technical specifications and catalogs. While efforts have been made to provide accurate details, inaccuracies may occur. It is advised to verify all information by contacting Hengst directly.***
The Hengst 445LEN1000-PWR10A00-V5,0-M-S8 (1010814B) is a hydraulic inline filter designed for efficient filtration of solids from fluids in hydraulic systems and lubricating oil systems. This model is intended for installation in pipelines and features a robust design with a nominal size of 1000. It utilizes a multilayer glass fiber material, designated as PWR10, providing a filtration grade of 10. The filter's housing is constructed from durable nodular cast iron and carbon steel, capable of withstanding a maximum working pressure of 450 bar and a nominal pressure of 445 bar. The unit includes an optical indicator for monitoring purposes and does not have a check valve or lid lifting device. Its design incorporates a cyclone effect for enhanced performance, and it features a two-parted bowl construction. The port designation is 2\" - 6000psi with horizontal positioning, adhering to SAE standards. Additionally, the filter supports HFC/HFA suitability and complies with DIN24550 standards. With its top mounting configuration and standard support cage material, this inline filter offers reliable performance under demanding conditions.
The Hengst 445LEN1000-PWR10A00-V5,0-M-S8 (1010814B) is a hydraulic inline filter designed for efficient filtration of solids from fluids in hydraulic systems and lubricating oil systems. This model is intended for installation in pipelines and features a robust design with a nominal size of 1000. It utilizes a multilayer glass fiber material, designated as PWR10, providing a filtration grade of 10. The filter's housing is constructed from durable nodular cast iron and carbon steel, capable of withstanding a maximum working pressure of 450 bar and a nominal pressure of 445 bar. The unit includes an optical indicator for monitoring purposes and does not have a check valve or lid lifting device. Its design incorporates a cyclone effect for enhanced performance, and it features a two-parted bowl construction. The port designation is 2\" - 6000psi with horizontal positioning, adhering to SAE standards. Additionally, the filter supports HFC/HFA suitability and complies with DIN24550 standards. With its top mounting configuration and standard support cage material, this inline filter offers reliable performance under demanding conditions.
Inline filters are used in hydraulic systems and lubricating oil systems for the filtration of solids from fluids. They are intended for installation in pipelines.
