BOSCH REXROTH
R345304016
$88.32 USD
- BOSCH REXROTH
- Material:R345304016
- Model:LIMIT SWITCH BNS 819-X496-99-R-11
Quantity in stock: 0
Unpacked Weight: 0.0732 kg
| 3D CAD | Download 3D CAD |
| 3D CAD | Download 3D CAD |
| Switching function version | Single-pole changeover/(NC: C+NC, NO: C+NO) |
| B10d value | 5x106 (wet area); 10x106 (dependent on current load (dry area)) |
| Productgroup ID | 17 |
| Connection type | Screw connection, without line |
| Permissible ambient temperature (max) | |
| Permissible ambient temperature | -5 °C ... +85 °C |
| Compatible | CKK, CKR, MKK/MKR-065/080/110/145/165, MLR-080/110, OBB, SGK, SOK, TKK |
| Electrical accessories for linear axes | Mechanical switch |
| Permissible ambient temperature (min) | |
| Switching frequency | 3.3 |
| Protection class | IP67 |
| Load current | |
| Max. permissible approach speed | 1 |
| Weight | 0.0732 |
| Functional principle | mechanical, roller |
| Use | Limit switch |
| Function indicator | no |
Technische Daten
|
Part number |
R345304016 | R347600305 | R117500151 | R117500162 | R023620301 | |
|
Functional principle |
mechanical, roller | |||||
|
Operating voltage |
V AC |
250 | ||||
|
Load current |
A |
≤ 5 | ||||
|
Switching function |
Single-pole changeover/(NC: C+NC, NO: C+NO) | |||||
|
Connection type |
Screw connection, without line | |||||
|
Function indication |
‒ | |||||
|
Switching frequency |
Hz |
3.3 | ||||
|
Maximum permissible starting speed |
m/s |
1 | ||||
|
Permissible ambient temperature (min ... max) |
-5 °C ... +85 °C | |||||
|
Protection type |
IP67 | |||||
|
B10d value |
5x106 (wet range); 10x106 (depending on current load (dry area)) | |||||
Mechanical switch without additional component
| 1) | R345304016 |
| 2) | R347600305 |
Mechanical switch with additional component
|
Certifications and approvals, housing |
|
|
|
|
|
Certifications and approvals, switching element |
|
|
|
|
